model | Working voltage (V) | Torque range(Kgf.cm) | No-load speed(rpm) | Use batch nozzle(mm) | Using screws(mm) | |
Mechanical tooth | Self-tapping | |||||
TGK-EC508 | 18~36 | 0.5~8.0 | 800~1500 | 4 | 1.2~2.5 | 2.0~3.0 |
TGK-EC518 | 18~36 | 3.0~18.0 | 700~1300 | 5/S5 | 2.0~3.05 | 2.0~3.5 |
TGK-EC528 | 18~36 | 5.0~28 | 600~1000 | 5 | 2.5~6.0 | 2.5~5.0 |
TGK-EC528S | 18~36 | 5.0~28 | 600~1000 | 1/4 | 2.5~6.0 | 2.5~5.0 |
1. Equipped with high-power high-voltage to low-voltage power supply, the metal part has reliable grounding wire, anti-static, safe and convenient;
2. It has overload and short-circuit protection function, and will automatically enter the protection state when the motor fails or the output power line is short-circuited. The load can be restored immediately after the load is removed or short-circuited;
3. The anti-shock voltage and current functions can be used normally even if the power grid has large fluctuations;
4. The power supply has a two-color indicator light, which can be very convenient to judge whether the machine appears.
5.The original matching high-power power supply has an instantaneous power of 240W, ensuring the normal operation of the machine under high torque.
6. High efficiency, high speed, high power and long life; imported DC motor, durable;
7. With infinitely adjustable torque and Speed function
8, structure according to ergonomic design, comfortable grip, balance of center of gravity, easy to use
9. Spindle is made of alloy steel CNC precision forming, strong impact resistance, high coaxiality of batch nozzle
10, light mechanical structure High-strength, one-piece molding material with very light weight.
